The HiLook IPC-T221H-M(2.8mm) is a compact 2MP PoE turret IP camera with a built-in microphone ("M") and IP67 weatherproofing, designed as an entry-level outdoor turret for straightforward CCTV coverage.
HiLook IPC-T221H-M(2.8mm) 2MP Fixed Turret IP Camera with Built-In Microphone
The HiLook IPC-T221H-M uses a 1/2.7" Progressive Scan CMOS sensor delivering up to 1920 × 1080 (2MP) resolution, with standard IR cut-filter day/night switching and a minimum colour illumination of 0.01 Lux (F2.0, AGC on).
The 2.8mm fixed lens gives a horizontal field of view of 105°, vertical FOV of 58° and diagonal FOV of 123°. The "-M" in the model name denotes a built-in microphone, and the camera is rated IP67 for outdoor installation.
2MP Imaging & Wide 105° Field of View
Maximum resolution is 1920 × 1080, with a wide 105° horizontal field of view suited to entrances, driveways and general-purpose outdoor coverage.
IR Night Vision
Standard IR cut-filter day/night switching provides black & white illumination in low light, suited to budget installations that don't require colour-at-night imaging.
Built-In Microphone
The "-M" designation adds a built-in microphone, allowing audio to be captured alongside video footage.
Power & IP67 Weatherproofing
Powered via PoE (IEEE 802.3af, Class 3, max 6.5W). Rated IP67 against dust and water ingress, suitable for permanent outdoor use.
KEY BENEFITS
- Wide 105° field of view covers large areas from one camera
- Built-in microphone adds audio context to recordings
- Compact, lightweight turret housing (approx. 320g)
- Single PoE cable for power and data
- IP67 rated for year-round outdoor use
KEY FEATURES
- 2MP (1920 × 1080) resolution
- 1/2.7" Progressive Scan CMOS sensor
- 2.8mm fixed lens — H.FOV 105°, V.FOV 58°, D.FOV 123°
- F2.0 aperture
- Min. illumination 0.01 Lux (colour, F2.0, AGC on), 0 Lux (IR)
- Built-in microphone
- PoE IEEE 802.3af Class 3 (max 6.5W)
- IP67 weather rating
- Weight approx. 320g
IDEAL FOR
- Entrances, driveways and general outdoor coverage
- Residential CCTV systems on a budget
- Retail shop fronts and small commercial premises
- Simple hybrid analog/IP camera additions where a low-cost IP turret is needed
- Sites wanting a wide field of view without needing 24/7 colour imaging
- Installations wanting basic audio capture alongside video
- Value-tier deployments prioritising cost over advanced low-light features
| Specification |
Details |
| Brand |
HiLook by Hikvision |
| Model |
IPC-T221H-M(2.8mm) |
| Product Type |
2MP Fixed Turret Network Camera with Microphone |
| Image Sensor |
1/2.7" Progressive Scan CMOS |
| Max Resolution |
1920 × 1080 (2MP) |
| Focal Length |
2.8mm (fixed) |
| Aperture |
F2.0 |
| Horizontal FOV |
105° |
| Vertical FOV |
58° |
| Diagonal FOV |
123° |
| Min. Illumination (Colour) |
0.01 Lux @ F2.0, AGC ON |
| Min. Illumination (B/W) |
0 Lux with IR |
| Day / Night |
IR cut filter |
| Audio |
Built-in microphone (M) |
| Power Supply |
PoE IEEE 802.3af Class 3 (max 6.5W) |
| Weather Rating |
IP67 |
| Weight |
Approx. 320g |
| Model Suffix Note |
"-M" = built-in microphone, added to the base IPC-T221H |
| Colour |
White (standard HiLook finish — confirm before publishing) |
| Warranty |
Manufacturer standard warranty (confirm current term before publishing) |
COMMON QUESTIONS
What does the "-M" mean in the model name?
It denotes a built-in microphone, added to the standard IPC-T221H turret camera.
What field of view does the 2.8mm lens give?
Horizontal 105°, vertical 58°, diagonal 123°.
Does it offer 24/7 colour imaging?
No, it uses standard IR cut-filter day/night switching, giving black & white imaging in low light.
Is it suitable for outdoor use?
Yes, it carries an IP67 rating.
How is it powered?
Via Power over Ethernet (PoE, IEEE 802.3af Class 3, max 6.5W).
