Description
Black Hikvision DS-2CD2386G2H-IS2U/SL Product Overview
The Hikvision DS-2CD2386G2H-IS2U/SL(2.8mm)(eF) in black is an 8MP AcuSense Powered-by-DarkFighter fixed turret network camera with integrated two-way audio and active deterrence. The exact base model remains DS-2CD2386G2H-IS2U/SL(2.8mm)(eF); black describes the supplied housing finish rather than changing the core model code.
Its 1/1.8-inch progressive-scan CMOS sensor records at up to 3840 × 2160. The fixed 2.8mm F1.0 lens provides a 105° horizontal field of view. The `/SL` hardware includes two built-in microphones, a 2W speaker, line audio input/output, one alarm input/output, a white warning strobe and audible warning. Infrared reaches up to 30 metres, and compatible memory cards up to 512GB are supported.
Key Benefits
-
Black metal finish: suited to installations where a darker housing is required.
-
4K 8MP detail: captures up to 3840 × 2160 for detailed monitoring.
-
DarkFighter imaging: the large sensor and F1.0 aperture support useful colour detail in low light.
-
AcuSense classification: supported events can distinguish human and vehicle targets.
-
Two-way audio: two microphones and a 2W speaker support compatible communication.
-
Active deterrence: a white warning strobe and audible warning can be linked to events.
-
External integration: line audio and alarm input/output are provided.
-
512GB local storage: compatible memory cards are supported.
-
IP67 protection: supports correctly installed indoor or outdoor use.
Key Features
- 8MP 3840 × 2160 maximum resolution
- Black metal turret housing
- 1/1.8-inch progressive-scan CMOS sensor
- 2.8mm fixed F1.0 lens
- 105° H, 56° V and 130° D field of view
- 0.0008-lux minimum colour illumination
- 30m infrared
- 120dB WDR
- Human and vehicle classification
- Two built-in microphones and 2W speaker
- Audio I/O and alarm I/O
- White strobe and audible warning
- 512GB card support
- 12V DC or PoE+
- IP67 weather resistance
Technical Specifications
| Base model |
DS-2CD2386G2H-IS2U/SL(2.8mm)(eF) |
| Colour |
Black finish |
| Camera type |
Fixed turret network camera with active deterrence |
| Sensor |
1/1.8-inch progressive-scan CMOS |
| Maximum resolution |
3840 × 2160 |
| Frame rate |
25fps in 50Hz or 24fps in 60Hz mode at 4K, with up to 30fps at supported lower resolutions |
| Minimum illumination |
0.0008 lux at F1.0; 0 lux with infrared |
| Lens |
2.8mm fixed focal lens, F1.0 |
| Field of view |
H 105°; V 56°; D 130° |
| Infrared |
Up to 30m |
| WDR |
120dB |
| Analytics |
Human and vehicle classification; face capture and scene-change detection |
| Built-in audio |
Two microphones and 2W speaker |
| External audio |
One line input and one line output |
| Alarm |
One input and one output |
| Deterrence |
White warning strobe and audible warning |
| Storage |
Compatible microSD-family cards up to 512GB |
| Network |
RJ45 10/100Mbps; ONVIF Profiles S, G and T |
| Power |
12V DC max 16W; IEEE 802.3at PoE+ Class 4 max 18W |
| Protection |
IP67 |
| Dimensions |
Ø138.3 × 115.4mm |
| Weight |
Approximately 780g |
Audio, Deterrence and Compatibility
The built-in microphones and 2W speaker support compatible two-way audio. The white strobe and audible warning provide active deterrence. The strobe is a warning signal rather than a general long-range scene illuminator.
Confirm NVR 8MP decoding, AcuSense, two-way audio, audio/alarm I/O, deterrence control, PoE+ capacity, storage and mounting compatibility before ordering.
Frequently Asked Questions
Is this the black version?
Yes. Black describes the finish; the base model remains DS-2CD2386G2H-IS2U/SL(2.8mm)(eF).
What is the maximum resolution?
3840 × 2160.
What is the field of view?
105° horizontal, 56° vertical and 130° diagonal.
What is the IR range?
Up to 30 metres.
Does it classify people and vehicles?
Yes.
Does it support two-way audio?
Yes.
Does it include active deterrence?
Yes.
Does it have alarm I/O?
Yes, one input and one output.
What storage is supported?
Compatible cards up to 512GB.
What power is required?
12V DC or PoE+.
