Hikvision DS-2CD2366G2P-ISU/SL Panoramic Overview
The Hikvision DS-2CD2366G2P-ISU/SL(2.8mm)(C) is a 6MP AcuSense panoramic fixed turret network camera that combines two 1/2.5-inch sensors and two fixed 2.8mm lenses into one stitched 180° image. Its maximum video resolution is 3632 × 1632 at up to 20fps, providing broad horizontal coverage from a single mounting point.
The camera uses Powered-by-DarkFighter imaging, 120dB WDR and infrared illumination up to 30 metres. Human and vehicle classification supports compatible motion and perimeter events. The `/SL` hardware also includes a built-in microphone, a 1.2W speaker, external line audio input/output, one alarm input/output, a white flashing warning light and audible-warning capability.
Key Benefits
-
Single 180° panoramic image: presents the stitched scene as one panoramic view rather than two independent channels.
-
6MP panoramic detail: captures up to 3632 × 1632 at 20fps.
-
Dual 2.8mm lenses: provide 180° horizontal and 81° vertical coverage.
-
DarkFighter low-light imaging: supports useful detail under limited illumination.
-
30m infrared: provides monochrome monitoring in darkness.
-
AcuSense classification: supported events can distinguish human and vehicle targets.
-
Integrated two-way audio: the built-in microphone and speaker support compatible communication.
-
Active deterrence: white flashing light and audible warning can be linked to supported events.
-
External integration: audio and alarm input/output support compatible equipment.
-
IP67 housing: supports correctly installed indoor or outdoor use.
Key Features
- 6MP maximum panoramic resolution of 3632 × 1632
- 20fps at maximum resolution
- Two 1/2.5-inch progressive-scan CMOS sensors
- Dual fixed 2.8mm lenses with F1.6 aperture
- 180° horizontal and 81° vertical field of view
- Minimum colour illumination of 0.003 lux at F1.6
- Infrared illumination up to 30 metres
- 120dB true wide dynamic range
- Human and vehicle classification for supported events
- Scene-change detection and perimeter protection
- Built-in microphone and 1.2W speaker
- External line audio input/output
- One alarm input and one alarm output
- White flashing warning light and audible warning
- Memory-card support up to 512GB
- 12V DC or IEEE 802.3af PoE
- IP67 weather resistance
Technical Specifications
| Model |
DS-2CD2366G2P-ISU/SL(2.8mm)(C) |
| Camera type |
Panoramic fixed turret network camera with active deterrence |
| Image sensors |
2 × 1/2.5-inch progressive-scan CMOS |
| Maximum resolution |
3632 × 1632 |
| Maximum frame rate |
20fps at 3632 × 1632 in 50Hz or 60Hz mode |
| Minimum illumination |
Colour: 0.003 lux at F1.6 with AGC on; black and white: 0 lux with infrared |
| Lens |
Dual fixed 2.8mm lenses, F1.6 |
| Field of view |
Horizontal 180°; vertical 81° |
| Infrared range |
Up to 30m, 850nm |
| Wide dynamic range |
120dB |
| Video compression |
H.265+, H.265, H.264+ and H.264; MJPEG on the sub-stream |
| Analytics |
Human and vehicle classification for supported motion, line-crossing, intrusion, region-entry and region-exit events; scene-change detection |
| Built-in audio |
Built-in microphone and 1.2W speaker; manufacturer states up to 95dB sound pressure at 10cm |
| External audio |
One line input and one line output |
| Alarm interface |
One input and one output |
| Active deterrence |
White flashing warning light and audible warning |
| Local storage |
Compatible microSD, microSDHC or microSDXC cards up to 512GB |
| Network interface |
1 × RJ45 10/100Mbps self-adaptive Ethernet port |
| Interoperability |
ONVIF Profiles S, G and T; ISAPI and SDK |
| Power |
12V DC, maximum 10.5W; IEEE 802.3af PoE Class 3, maximum 12.5W |
| Operating conditions |
-30°C to 60°C; relative humidity 95% or less, non-condensing |
| Housing |
Metal base and cover, white finish |
| Protection |
IP67; Hikvision states no specific anti-corrosion protection level for this model |
| Dimensions |
Ø140 × 145.6mm |
| Weight |
Approximately 940g |
Understanding the Panoramic Image
The two sensors are stitched into one 180° panoramic image. This is different from a dual-channel camera that supplies two separate streams. Confirm that the recorder supports the 3632 × 1632 panoramic resolution and required decoding load before ordering.
Audio, Deterrence and Compatibility
The built-in microphone and speaker support compatible two-way communication. The white flashing light and audible warning can be linked to supported events. External line audio and alarm interfaces are available for compatible equipment.
The warning light is a deterrence signal rather than a claimed long-range white scene illuminator. Confirm NVR panoramic decoding, AcuSense, two-way audio, alarm and deterrence controls, standard PoE capacity, storage-card support and mounting accessories before ordering.
Frequently Asked Questions
What is the exact model?
DS-2CD2366G2P-ISU/SL(2.8mm)(C).
What is the maximum resolution?
3632 × 1632, described by Hikvision as 6MP panoramic imaging.
Does it provide one panoramic image or two channels?
It provides one stitched panoramic image covering the camera’s scene.
What is the field of view?
180° horizontal and 81° vertical.
What is the infrared range?
Up to 30 metres under manufacturer test conditions.
Does it classify people and vehicles?
Yes, for supported event types.
Does it support two-way audio?
Yes. It has a built-in microphone and speaker.
Does it include active deterrence?
Yes. It includes a white flashing warning light and audible warning.
Does it require PoE+?
No. Hikvision specifies standard IEEE 802.3af PoE Class 3.
What storage and protection are supported?
Compatible cards up to 512GB and IP67 weather resistance.
