Grey Hikvision DS-2CD2366G2H-IU Product Overview
The Hikvision DS-2CD2366G2H-IU(2.8mm)(eF) in grey is a 6MP AcuSense Powered-by-DarkFighter fixed turret network camera with a built-in microphone. The exact base model is DS-2CD2366G2H-IU(2.8mm)(eF); grey describes the housing finish supplied in this listing rather than changing the core model code.
Its 1/2.4-inch progressive-scan CMOS sensor records at up to 3200 × 1800, while the fixed 2.8mm F1.0 lens provides a wide 114.8° horizontal field of view. The camera also provides infrared illumination up to 30 metres, 120dB WDR, human and vehicle classification, face capture, scene-change detection and memory-card support up to 512GB.
Key Benefits
-
Grey housing finish: suited to installations where the supplied grey colour matches the surrounding surface.
-
Detailed 6MP monitoring: captures up to 3200 × 1800 for high-detail live viewing and playback.
-
Wide 2.8mm coverage: the 114.8° horizontal view suits entrances, shops, offices and broad surveillance areas.
-
DarkFighter imaging: the F1.0 lens supports useful colour detail under limited illumination.
-
30m infrared: provides monochrome monitoring in darkness.
-
AcuSense classification: supported events can distinguish human and vehicle targets.
-
Built-in microphone: records audio without implying speaker playback.
-
Weather resistance: the metal turret housing is rated IP67.
Key Features
- 6MP maximum resolution of 3200 × 1800
- Grey-finish metal turret housing
- 1/2.4-inch progressive-scan CMOS sensor
- 2.8mm fixed F1.0 lens
- Approximately 114.8° horizontal field of view
- Minimum colour illumination of 0.001 lux
- Infrared illumination up to 30 metres
- 120dB WDR
- Human and vehicle classification
- Face capture and scene-change detection
- Built-in microphone
- Memory-card support up to 512GB
- 12V DC or IEEE 802.3af PoE
- IP67 protection
Technical Specifications
| Base model |
DS-2CD2366G2H-IU(2.8mm)(eF) |
| Colour |
Grey finish |
| Camera type |
Fixed turret network camera |
| Image sensor |
1/2.4-inch progressive-scan CMOS |
| Maximum resolution |
3200 × 1800 |
| Maximum frame rate |
25fps at full resolution in 50Hz mode; 24fps at full resolution in 60Hz mode, with up to 30fps at supported lower resolutions |
| Minimum illumination |
Colour: 0.001 lux at F1.0 with AGC on; 0 lux with infrared |
| Lens |
2.8mm fixed focal lens, F1.0 |
| Field of view |
Approximately 114.8° horizontal |
| Physical adjustment |
Pan 0° to 360°, tilt 0° to 75° and rotation 0° to 360° during installation |
| Infrared range |
Up to 30m |
| Wide dynamic range |
120dB |
| Analytics |
Human and vehicle classification for supported events; face capture and scene-change detection |
| Built-in audio |
Built-in microphone |
| Speaker and external interfaces |
No built-in speaker, external audio input/output or alarm input/output stated |
| Local storage |
Compatible microSD-family cards up to 512GB |
| Power |
12V DC or IEEE 802.3af PoE; manufacturer product data states maximum consumption up to 8W |
| Operating conditions |
-30°C to 60°C; relative humidity 95% or less, non-condensing |
| Protection |
IP67 weather resistance |
Detection, Audio and Compatibility
AcuSense can classify human and vehicle targets for supported events. The built-in microphone records audio, but no speaker or audio output is stated, so this listing does not claim two-way audio.
Confirm that the grey finish, NVR 6MP decoding, required frame rate, analytics, audio recording, PoE capacity, storage card and mounting accessories meet the installation requirements before ordering.
Frequently Asked Questions
Is grey part of the Hikvision model code?
No. The base model is DS-2CD2366G2H-IU(2.8mm)(eF); grey describes the housing finish supplied in this listing.
What is the maximum resolution?
3200 × 1800, commonly described as 6MP.
What lens is fitted?
A fixed 2.8mm F1.0 lens.
What is the field of view?
Approximately 114.8° horizontal.
What is the infrared range?
Up to 30 metres under manufacturer test conditions.
Does it classify people and vehicles?
Yes, for supported event types.
Does it have a microphone?
Yes. It has a built-in microphone.
Does it support two-way audio?
No built-in speaker or audio output is stated.
What storage is supported?
Compatible cards up to 512GB.
What is the protection rating?
IP67.
