The Hikvision HIK/POE is a professional-grade 60W Gigabit Ultra PoE injector designed to deliver reliable power and high-speed data connectivity to power-hungry IP security devices. Ideal for high-performance pan-tilt-zoom (PTZ) cameras, active deterrence domes, and specialized access control terminals, it eliminates local power outlet requirements and simplifies network camera deployment over a single Ethernet cable.
Hikvision HIK/POE 60W Gigabit Ultra PoE Injector
This high-power injector merges electrical power with a Gigabit network connection, outputting up to 60W over standard Category cabling. Designed to meet the demanding requirements of speed domes and motorized cameras, it supports Gigabit speeds (10/100/1000 Mbps) to ensure lag-free video transmission. Built-in protection protects connected equipment from surges and short circuits.
Housed in a compact, durable enclosure, the injector is designed for easy wall or desktop installation. With standard plug-and-play setup, it automatically detects and delivers the correct power level to downstream PD devices, providing a safe, reliable, and cost-effective power solution for commercial security networks.
60W Ultra High Power Output
Delivers up to 60 Watts of Power over Ethernet, which is twice the power of standard PoE+ switches. This ensures reliable operation for motorized PTZs, built-in camera heaters, and high-power strobes.
Full Gigabit Data Speeds
Supports Gigabit network transmission speeds (10/100/1000 Mbps) for both input and output. This ensures that high-resolution 4K video streams pass through without bottlenecks.
Integrated Surge Protection
Equipped with advanced surge protection up to 6KV to protect downstream cameras and upstream NVR ports from lightning strikes, static discharges, and electrical surges.
Plug-and-Play Installation
Requires no software configuration or programming. Simply connect the incoming network LAN cable, the outgoing PoE camera cable, and plug it into a standard AC power outlet.
Intelligent Auto-Sensing
Automatically detects the power requirements of the connected camera, ensuring safe power distribution and preventing damage to non-PoE network devices.
Compact, Mountable Housing
Features a durable casing with integrated mounting slots for wall, desk, or server cabinet installation, keeping security cabling clean and organized.
Note: This injector supports high-power devices up to 60W. Always verify the maximum wattage requirements of your security camera or device before connecting to prevent underpowering issues.
KEY BENEFITS
- 60W output provides ample power for heavy-duty motorized PTZ dome cameras.
- Gigabit Ethernet ports support lag-free 4K and multi-sensor video streams.
- Surge protection shields expensive security hardware from electrical spikes.
- Eliminates the cost and labor of installing AC outlets near camera locations.
- Auto-sensing technology ensures safe power delivery to connected equipment.
- Compact form factor fits easily in network closets and security cabinets.
- Built-in LED indicators provide clear, instant status of power and PoE activity.
- Plug-and-play deployment requires no complex network configuration.
- Supports standard Cat5e, Cat6, and Cat6a copper network cabling runs.
- Includes a standard UK AC power cable for immediate out-of-the-box setup.
KEY FEATURES
- Product Model: Hikvision HIK/POE
- Product Type: 60W Gigabit Ultra PoE Injector
- Ethernet Data Rate: 10/100/1000 Mbps
- PoE Output Power: Up to 60 Watts
- Standard Compliance: IEEE 802.3at / IEEE 802.3af compatible
- AC Input Voltage: 100 to 240 VAC, 50/60 Hz
- Input Current Rating: Max. 1.5 A
- Power Pin Assignment: Pairs 1/2(+), 3/6(-) and 4/5(+), 7/8(-)
- Integrated Protection: Short-circuit & overcurrent protection
- Surge Protection Rating: ±6KV common mode, ±2KV differential mode
- LED Indicators: AC Power (Green), PoE Active (Yellow)
- Casing Material: Flame-Retardant ABS Casing
- Operating Temperature Range: -10 °C to +45 °C
- Product Weight: Approx. 350 g (0.77 lb.)
- Cabling Compatibility: Cat5e, Cat6, Cat6a UTP/FTP
IDEAL FOR
- Motorized PTZ speed dome installations
- Active deterrence cameras with strobe/audio
- Outdoor camera enclosures with built-in heaters
- Multi-sensor panoramic camera setups
- Access control door terminal power
- IP video intercom door stations
- Wireless access point outdoor bridges
- IP public address horn speakers
- Retrofitting non-PoE network switches
- Extending PoE power over long cable runs
- Temporary construction site camera poles
- Remote surveillance station setups
SYSTEM COMPATIBILITY
- Fully compatible with Hikvision IP PTZ dome cameras
- Compatible with third-party IP cameras requiring high-power PoE
- Supports standard IEEE 802.3af/at PoE and PoE+ devices
- Connects to standard non-PoE network switches and routers
- Compatible with standard Cat5e, Cat6, and Cat6a network cables
- Works with standard UK mains power AC outlets (100-240V)
- Suitable for use in IP-based access control and intercom systems
- Integrates with standard server racks and cable trays
- Compatible with standard RJ45 network patch leads
- Supports Gigabit network cards and NVR network ports
- Designed for 24/7 continuous network power transmission
- Works with outdoor cameras housed in protective heating casings
- Compatible with standard DIN rail mount accessories if modified
TECHNICAL SPECIFICATIONS
| Specification |
Details |
| Brand |
Hikvision |
| Model |
HIK/POE |
| Product Type |
PoE Injector |
| Ethernet Ports |
1 × Gigabit LAN In, 1 × Gigabit PoE Out |
| Data Rate |
10/100/1000 Mbps |
| Output Power |
Up to 60W (Ultra PoE / High PoE) |
| Power Supply Standards |
IEEE 802.3at / IEEE 802.3af compliant |
| Input Voltage |
100 to 240 VAC (50/60 Hz) |
| Input Current |
Max. 1.5 A |
| PoE Pin Assignment |
1/2(+), 3/6(-), 4/5(+), 7/8(-) |
| LED Indicators |
Power (Green), PoE Status (Yellow/Amber) |
| Enclosure Protection |
Flame-Retardant ABS Casing |
| Weatherproof Rating |
Indoor Use Only |
| Mounting Options |
Desktop or Wall Mountable |
| Operating Temperature |
-10 °C to +45 °C (14 °F to 113 °F) |
| Operating Humidity |
5% to 90% RH (non-condensing) |
| Storage Temperature |
-20 °C to +70 °C (-4 °F to 158 °F) |
| Surge Protection |
Differential mode ±2KV, Common mode ±6KV |
| Physical Dimensions |
Compact profile housing |
| Product Weight |
Approx. 350 g (0.77 lb.) |
| Plug Type |
UK Standard AC Power Cord included |
| Compliance Certifications |
CE, FCC, RoHS |
| Cable Compatibility |
Cat5e, Cat6, Cat6a UTP/FTP |
FREQUENTLY ASKED QUESTIONS (FAQs)
What does the Hikvision HIK/POE injector do?
The HIK/POE injector combines electrical power with network data over a single Ethernet cable, allowing you to power PoE-compatible cameras without a PoE switch.
What is the power output of this injector?
It outputs up to 60 Watts of power, making it an Ultra PoE (High PoE) injector suitable for motorized PTZ cameras that require high wattage.
Does it support Gigabit network speeds?
Yes, both the LAN input and PoE output ports support full Gigabit speeds (10/100/1000 Mbps).
Can I use this with non-PoE devices?
The injector features auto-sensing technology which prevents power transmission if a non-PoE device is connected, protecting your equipment from damage.
Is it compatible with third-party cameras?
Yes, it is compatible with all IP cameras that follow the standard IEEE 802.3af, 802.3at, or Ultra PoE power specifications.
Does it include a power cable?
Yes, it comes with a standard UK mains AC power cable to plug the injector into a wall outlet.
Is it waterproof?
No, the injector is rated for indoor use only. If used outdoors, it must be housed in a weatherproof enclosure.
How far can the Ethernet cable run?
It supports standard Ethernet transmission distances up to 100 meters (328 feet) from the injector to the camera.
Does it have surge protection?
Yes, it features built-in surge protection up to 6KV to safeguard your camera and network switch from lightning and electrical surges.
What do the LEDs indicate?
The green LED indicates the device is powered on, and the yellow/amber LED indicates that PoE power is actively being supplied to a connected camera.
