The HiLook NVR-108MH-K/8P is an 8-channel 4K network video recorder with 8 built-in PoE ports, designed to power and record up to eight IP cameras through a single plug-and-play device. It supports cameras up to 8MP, H.265+ compression, deep-learning Motion Detection 2.0 and facial detection, making it a capable and cost-effective recorder for homes and businesses.
HiLook NVR-108MH-K/8P 8-Channel 4K PoE Network Video Recorder
The HiLook NVR-108MH-K/8P is an 8-channel network video recorder with eight integrated Power-over-Ethernet ports, allowing IP cameras to be connected and powered using a single network cable each. This plug-and-play design greatly simplifies installation and removes the need for a separate PoE switch or power supplies for the cameras.
Supporting camera resolutions up to 8MP with efficient H.265+ compression, the recorder captures high-detail footage while minimising storage use. It is well suited to residential and small-to-medium commercial CCTV systems that require reliable recording with smart detection.
8 Built-In PoE Ports
The NVR-108MH-K/8P includes 8 self-adaptive PoE ports (IEEE 802.3af/at) with a total PoE power budget of up to 75W. Each camera connects with a single cable that carries both data and power, reducing cabling and installation time.
4K Recording and Playback
The recorder supports IP cameras up to 8MP and outputs live view and playback in 4K (3840 × 2160) via HDMI, with a simultaneous VGA output. It provides up to 80 Mbps of incoming bandwidth and synchronous 8-channel playback for reviewing footage.
Deep-Learning Smart Detection
Using deep-learning Motion Detection 2.0, the NVR classifies human and vehicle targets and only notifies you when a person or vehicle is detected, dramatically reducing false alarms from animals, foliage or changing light. It also supports facial detection and picture comparison for more advanced applications.
Efficient H.265+ Compression
H.265+ compression reduces storage requirements by up to 75% compared with H.264, allowing longer recording retention on a single hard drive without sacrificing image quality.
Flexible Storage and Connectivity
A single SATA bay supports a 3.5" hard drive of up to 16TB (sold separately). The recorder supports ONVIF for third-party camera compatibility and remote access via the HiLookVision / Hik-Connect app for live view, playback and notifications from anywhere.
KEY BENEFITS
- 8 built-in PoE ports simplify installation — no separate switch required
- Records up to eight 8MP IP cameras
- 4K HDMI output for sharp live view and playback
- Motion Detection 2.0 reduces false alarms
- Facial detection for advanced monitoring
- H.265+ compression saves up to 75% storage
- Supports a single hard drive up to 16TB
- ONVIF support for third-party cameras
- Remote viewing via HiLookVision / Hik-Connect
- Ideal for homes and small-to-medium businesses
KEY FEATURES
- 8-channel network video recorder
- 8 built-in PoE ports (802.3af/at), ≤75W budget
- Up to 8MP IP camera resolution
- H.265+/H.265/H.264+/H.264 compression
- 4K (3840 × 2160) HDMI output + VGA
- Up to 80 Mbps incoming bandwidth
- Deep-learning Motion Detection 2.0 (human/vehicle)
- Facial detection and picture comparison
- Synchronous 8-channel playback
- 1 × SATA HDD up to 16TB (not included)
- ONVIF support
- HiLookVision / Hik-Connect remote access
- Dimensions approx. 320 × 240 × 48mm
IDEAL FOR
- Homes and apartments
- Small and medium businesses
- Retail shops
- Offices
- Warehouses
- Plug-and-play PoE camera systems
- IP CCTV installations up to 8 cameras
| Specification |
Details |
| Brand |
HiLook |
| Model |
NVR-108MH-K/8P |
| Product Type |
Network Video Recorder (NVR) |
| Channels |
8 |
| PoE Ports |
8 built-in (802.3af/at) |
| PoE Budget |
Up to 75W |
| Max Camera Resolution |
8MP |
| Video Compression |
H.265+/H.265/H.264+/H.264 |
| HDMI Output |
4K (3840 × 2160) |
| VGA Output |
Yes (simultaneous) |
| Incoming Bandwidth |
Up to 80 Mbps |
| Smart Detection |
Motion Detection 2.0 (human/vehicle), Facial Detection |
| Playback |
Synchronous 8-channel |
| Storage |
1 × SATA HDD up to 16TB (not included) |
| Network Interface |
1 × RJ45 10/100/1000 Mbps |
| Protocols |
TCP/IP, ONVIF, DDNS, NTP, RTSP, HTTP/HTTPS |
| Remote Access |
HiLookVision / Hik-Connect |
| Dimensions |
Approx. 320 × 240 × 48mm |
| Operating Temperature |
-10°C to 55°C |
| Warranty |
Not specified |
COMMON QUESTIONS
What is the NVR-108MH-K/8P used for?
It is an 8-channel PoE network video recorder used to power and record up to eight IP cameras through a single plug-and-play device, ideal for home and business CCTV systems.
Does it have built-in PoE?
Yes. It has 8 built-in PoE ports (802.3af/at) with a total budget of up to 75W, so no separate PoE switch is required.
What camera resolution does it support?
It supports IP cameras up to 8MP with H.265+ compression.
How many hard drives does it take?
It has a single SATA bay supporting one hard drive up to 16TB. The drive is not included.
Does it reduce false alarms?
Yes. Deep-learning Motion Detection 2.0 classifies human and vehicle targets, greatly reducing false alarms from animals or foliage.
Can I view it remotely?
Yes. It supports the HiLookVision / Hik-Connect app for remote live view, playback and notifications.
Does it work with third-party cameras?
Yes. It supports ONVIF for compatibility with third-party IP cameras.
