The HiLook DVR-204G-M1/T is a 4-channel 1U Turbo HD digital video recorder supporting hybrid analog and IP camera inputs with two-way audio over coax and all-channel motion detection. It is designed for small sites needing straightforward local recording.
HiLook DVR-204G-M1/T 4-Channel 1080p Lite H.265 Turbo HD DVR
The DVR-204G-M1/T accepts 4 analog channels (HDTVI/AHD/CVI/CVBS) via a 4-ch BNC interface (1.0 Vp-p, 75Ω, coaxitron support), plus up to 5 additional IP camera channels, giving installers flexibility to run a hybrid analog/IP system from a single recorder. Video is encoded using H.265 Pro+/H.265 Pro/H.265 compression to reduce storage and bandwidth requirements.
Motion detection is supported across all channels, and two-way audio over coax is available on HDTVI channels, allowing audio communication without separate cabling. Simultaneous HDMI and VGA outputs support resolutions up to 1920 × 1080 at 60Hz.
Hybrid Analog/IP Recording
4 analog (HDTVI/AHD/CVI/CVBS) channels plus up to 5 IP camera channels can be combined on one recorder, supporting mixed analog/IP installations without needing a separate NVR.
All-Channel Motion Detection
Motion detection technology is supported across all analog channels, helping flag movement events for review without needing to scrub through continuous footage.
Two-Way Audio Over Coax
All HDTVI channels support two-way audio transmitted over the existing coaxial cable, removing the need for separate audio wiring runs.
Video Output
The recorder provides simultaneous HDMI and VGA output, each supporting up to 1920 × 1080, 1280 × 1024 or 1280 × 720 at 60Hz.
KEY BENEFITS
- Flexible hybrid installation combining analog and IP cameras on one recorder
- Lower storage costs from H.265 Pro+ compression
- Two-way audio over coax without additional cabling
- All-channel motion detection flags events for quicker review
- Simultaneous HDMI/VGA output up to 1080p/60Hz
KEY FEATURES
- 4-channel 1U hybrid DVR (HDTVI/AHD/CVI/CVBS) via 4-ch BNC (1.0 Vp-p, 75Ω)
- Coaxitron connection support
- Up to 5-ch IP camera input
- H.265 Pro+ / H.265 Pro / H.265 video compression
- Motion detection across all channels
- Two-way audio over coax on HDTVI channels
- 1 × HDMI output, up to 1920 × 1080 @ 60Hz
- 1 × VGA output, up to 1920 × 1080 @ 60Hz
IDEAL FOR
- Small retail units and shops
- Home and residential CCTV systems
- Small offices needing hybrid analog/IP recording
- Sites wanting audio communication without extra cabling
- Budget-conscious 4-channel installations
- Simple upgrades from older analog-only DVRs
- Locations wanting event review via all-channel motion flagging
- Sites needing high-resolution HDMI/VGA output for a wall-mounted monitor
| Specification |
Details |
| Brand |
HiLook by Hikvision |
| Model |
DVR-204G-M1/T |
| Product Type |
Digital Video Recorder |
| Channels |
4-channel analog (HDTVI/AHD/CVI/CVBS), plus up to 5-ch IP |
| Analog Video Input |
4-ch BNC (1.0 Vp-p, 75Ω), coaxitron supported |
| Video Compression |
H.265 Pro+ / H.265 Pro / H.265 |
| Smart Detection |
Motion detection, all channels |
| Audio |
Two-way audio over coax (HDTVI channels) |
| Video Output |
1 × HDMI, 1 × VGA, up to 1920×1080 @ 60Hz |
| Power / HDD / Weight / Dimensions |
Not confirmed from the pages reviewed — verify before publishing |
| Warranty |
Manufacturer standard warranty (confirm current term before publishing) |
COMMON QUESTIONS
How many cameras can the DVR-204G-M1/T support?
4 analog channels (HDTVI/AHD/CVI/CVBS) plus up to 5 additional IP camera channels.
Does it support two-way audio?
Yes, over coax on HDTVI channels, without needing separate audio cabling.
Does it support motion detection?
Yes, motion detection is supported across all channels.
What video outputs are available?
Simultaneous HDMI and VGA output, both up to 1920 × 1080 at 60Hz.
Can I mix analog and IP cameras?
Yes, up to 5 additional IP camera channels can be added alongside the 4 analog channels.
What compression does it use?
H.265 Pro+, H.265 Pro and H.265, for efficient storage use.
Does it support coaxitron cameras?
Yes, the analog inputs support coaxitron connections for compatible cameras.
Is this suitable for a small shop or home installation?
Yes, its 4-channel hybrid design suits small retail, residential and office CCTV systems.
