The HiLook DVR-208G-M1/T is an 8-channel 1U Turbo HD digital video recorder supporting hybrid analog and IP camera inputs, 1080p Lite recording and deep-learning motion detection. It is designed for small to medium sites needing straightforward local recording with smart analytics.
HiLook DVR-208G-M1/T 8-Channel 1080p Lite H.265 Turbo HD DVR
The DVR-208G-M1/T accepts 8 analog channels (HDTVI/AHD/CVI/CVBS) plus up to 10 additional IP camera channels, giving installers the flexibility to run a hybrid analog/IP system from a single recorder. Video is encoded using H.265 Pro+/H.265 Pro/H.265 compression to reduce storage and bandwidth requirements.
Deep-learning-based Motion Detection 2.0 classifies movement as human or vehicle across supported channels, and two-way audio over coax is supported on HDTVI channels, allowing audio communication without separate cabling.
Hybrid Analog/IP Recording
8 analog (HDTVI/AHD/CVI/CVBS) channels plus up to 10 IP camera channels can be combined on one recorder, supporting mixed analog/IP installations without needing a separate NVR.
Motion Detection 2.0
Deep-learning-based Motion Detection 2.0 classifies detected movement as human or vehicle, reducing false alerts from environmental movement, with quick search by object or event type during playback.
1080p Lite & Storage
1080p Lite recording is supported across all channels for an image effect similar to full 1080p at reduced bitrate. Storage uses a SATA interface supporting drives up to 4TB capacity (confirm bay count before publishing — see notes below).
Connectivity & Output
The recorder provides simultaneous HDMI and VGA video output for connecting to a monitor or display.
KEY BENEFITS
- Reduced false alarms from human/vehicle motion classification
- Flexible hybrid installation combining analog and IP cameras on one recorder
- Lower storage costs from H.265 Pro+ compression
- Two-way audio over coax without additional cabling
- Simultaneous HDMI/VGA output for flexible display options
KEY FEATURES
- 8-channel 1U hybrid DVR (HDTVI/AHD/CVI/CVBS) plus up to 10-ch IP camera input
- H.265 Pro+ / H.265 Pro / H.265 video compression
- Deep-learning Motion Detection 2.0 — human and vehicle classification
- Two-way audio over coax on HDTVI channels
- 1080p Lite recording support across all channels
- SATA HDD interface, up to 4TB per disk
- Simultaneous HDMI/VGA video output
- Power consumption ≤ 10W (without HDD)
- Weight ≤ 1kg (without HDD)
- Dimensions 263 × 225 × 48mm
IDEAL FOR
- Small retail units and shops
- Home and residential CCTV systems
- Small offices needing hybrid analog/IP recording
- Sites wanting audio communication without extra cabling
| Specification |
Details |
| Brand |
HiLook by Hikvision |
| Model |
DVR-208G-M1/T |
| Product Type |
Digital Video Recorder |
| Channels |
8-channel analog (HDTVI/AHD/CVI/CVBS), plus up to 10-ch IP |
| Recording Resolution |
1080p Lite support across all channels |
| Video Compression |
H.265 Pro+ / H.265 Pro / H.265 |
| Smart Detection |
Motion Detection 2.0 — human and vehicle classification (deep learning) |
| Audio |
Two-way audio over coax (HDTVI channels) |
| Storage |
SATA interface, up to 4TB per disk (bay count unconfirmed — verify before publishing) |
| Video Output |
HDMI + VGA (simultaneous) |
| Power Consumption |
≤ 10W (without HDD) |
| Weight |
≤ 1kg (without HDD) |
| Dimensions |
263 × 225 × 48mm |
| Warranty |
Manufacturer standard warranty (confirm current term before publishing) |
COMMON QUESTIONS
How many cameras can the DVR-208G-M1/T support?
8 analog channels (HDTVI/AHD/CVI/CVBS) plus up to 10 additional IP camera channels, for a hybrid analog/IP installation.
What HDD size does it support?
Up to 4TB capacity per disk via its SATA interface.
Does it support human/vehicle detection?
Yes, deep-learning Motion Detection 2.0 classifies movement as human or vehicle to reduce false alarms.
Does it support two-way audio?
Yes, over coax on HDTVI channels, without needing separate audio cabling.
What video outputs are available?
Simultaneous HDMI and VGA output.
What is 1080p Lite?
A reduced-bitrate recording mode giving an image effect similar to full 1080p, supported across all channels.
