The Hikvision DS-2CD2H86G2-IZS(C) is a professional 8 Megapixel (4K) AcuSense motorized varifocal turret network camera. Designed for premium commercial and residential installations, it combines Ultra HD imaging, DarkFighter low-light performance, and deep learning analytics to provide dependable, high-resolution security surveillance.
Hikvision DS-2CD2H86G2-IZS(C) 8MP AcuSense Turret Camera
This high-performance turret camera delivers ultra-high-definition 4K video (3840 x 2160) at up to 20 fps. Equipped with a motorized 2.8 to 12 mm varifocal lens, users can zoom and focus the camera remotely from a web browser or NVR. DarkFighter technology ensures color imaging down to 0.003 Lux, maintaining visual clarity long before switching to black-and-white infrared mode.
The integrated AcuSense engine provides advanced analytics that classify human and vehicle targets, ignoring false alarms from environmental factors like wind-blown trees or passing animals. Housed in a rugged IP67 weatherproof turret dome, it is built to operate reliably under extreme outdoor conditions.
4K Ultra HD Resolution Detail
Providing four times the pixel count of standard 1080p, this 8 Megapixel camera captures extremely high-detail video, enabling operators to zoom into recorded footage to identify faces, logos, or license plates clearly.
Motorized Zoom and Focus
The motorized 2.8 to 12 mm varifocal lens allows the installer to adjust the zoom and focus remotely. This saves significant setup time and allows easy re-adjustment of the field of view after installation.
AcuSense Deep Learning Engine
The onboard AI classifies humans and vehicles, filtering out up to 90% of false alarms from wind, rain, shadows, or animals, ensuring only relevant alerts are sent to security staff.
Note: This camera is part of Hikvision's professional security line. To ensure full compatibility with NVR features, advanced deep learning analytics, and firmware updates, professional installation and network configuration are highly recommended.
KEY BENEFITS
- 8 MP 4K resolution provides exceptional detail for forensic review.
- Motorized varifocal lens allows remote adjustments of optical zoom.
- DarkFighter technology captures vivid color footage in dark environments.
- 120 dB True WDR balances exposure in challenging backlight situations.
- AcuSense algorithms filter out up to 90% of false alarms.
- IP67 weatherproofing ensures reliable performance in heavy rain and snow.
- Rugged aluminum casing resists impacts and tampering.
- Supports local edge storage via microSD cards up to 256 GB.
KEY FEATURES
- Varifocal turret IP camera
- Resolution: 8 Megapixel (3840 × 2160)
- Image Sensor: 1/1.8" Progressive Scan CMOS
- Lens Type: Motorized varifocal 2.8 to 12 mm
- Wide Dynamic Range: 120 dB True WDR
- Low Light: DarkFighter technology
- IR Range: Up to 40 meters
- Smart Analytics: AcuSense Human & Vehicle Classification
- Audio Interfaces: 1 input / 1 output
- Alarm Interfaces: 1 input / 1 output
- Storage: MicroSD slot up to 256 GB
- Ingress Protection: IP67 weatherproof
- Power: 12 VDC or PoE (802.3at)
- Color: White
IDEAL FOR
- Commercial parking lots
- Industrial loading yards
- School campus walkways
- Retail plaza perimeters
- Storage facility driveways
- High-end residential driveways
- Corporate entry vestibules
- Office corridors
SYSTEM COMPATIBILITY
- Compatible with Hikvision DS-7600, DS-7700, and DS-9600 Series NVRs
- Supports Hik-Connect mobile app (iOS & Android) for remote alerts
- Integrates with iVMS-4200 and iVMS-5200 software
- ONVIF Profile S, Profile G, and Profile T compliant
- Powered via PoE (802.3at Class 4) or 12 VDC
TECHNICAL SPECIFICATIONS
| Specification |
Details |
| Brand |
Hikvision |
| Model |
DS-2CD2H86G2-IZS(C) |
| Product Type |
AcuSense Turret Camera |
| Resolution |
8 MP (3840 × 2160) |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Lens Type |
Motorized varifocal 2.8 to 12 mm |
| WDR |
120 dB True WDR |
| IR Range |
Up to 40 meters |
| Smart Analytics |
AcuSense Human & Vehicle Classification |
| Ingress Protection |
IP67 weatherproof |
| Dimensions |
145 mm × 145 mm × 120 mm |
| Weight |
1.1 kg |
FREQUENTLY ASKED QUESTIONS (FAQs)
Can it run on 12VDC power?
Yes. It can be powered via a local 12VDC power adapter or via standard PoE (802.3at) over the network cable.
Does this turret camera have a built-in microphone?
No, this model does not have a built-in microphone, but it features audio input and output terminals to connect an external microphone or speaker.
Can the camera be mounted on a wall?
Yes. Turret cameras can be mounted directly onto flat walls or ceilings. You can also pair it with a compatible wall mount bracket or junction box.
