Hikvision DS-2CD23166G3-I2UY Product Overview
The Hikvision DS-2CD23166G3-I2UY(2.8mm)(eF) is a 16MP AcuSense Powered-by-DarkFighter fixed turret network camera. Its 1/1.8-inch progressive-scan CMOS sensor records at up to 4608 × 3456, while the fixed 2.8mm F1.6 lens provides a 94.5° horizontal field of view.
The camera provides infrared illumination up to 40 metres, 130dB WDR and human and vehicle classification for supported motion and perimeter events. The 2U hardware includes an arrayed dual microphone for audio capture, and compatible memory cards up to 512GB are supported. This exact I2UY model does not have a manufacturer-stated speaker, external audio input/output or alarm input/output.
Key Benefits
-
16MP image detail: captures up to 4608 × 3456 for high-detail monitoring and playback.
-
DarkFighter low-light imaging: supports useful detail under limited illumination.
-
40m infrared: built-in IR supports monochrome monitoring in darkness.
-
AcuSense classification: supported events can distinguish human and vehicle targets.
-
130dB WDR: helps preserve detail in high-contrast scenes.
-
Arrayed dual microphone: integrated audio capture with environmental-noise filtering.
-
512GB local storage: compatible microSD-family cards are supported.
-
Protected metal housing: IP67 and NEMA 4X moderate anti-corrosion protection.
Key Features
- 16MP maximum resolution of 4608 × 3456
- 12.5fps at maximum resolution in 50Hz mode and 15fps in 60Hz mode
- 20fps at 4608 × 2592
- Up to 25/30fps at supported 4K and lower resolutions
- 1/1.8-inch progressive-scan CMOS sensor
- 2.8mm fixed F1.6 lens
- 94.5° horizontal, 69.9° vertical and 123.2° diagonal field of view
- Minimum colour illumination of 0.0008 lux at F1.6 with AGC enabled
- Infrared illumination up to 40 metres
- 130dB WDR
- Human and vehicle classification and face capture
- Arrayed dual microphone
- Memory-card support up to 512GB
- 12V DC or IEEE 802.3af PoE
- IP67 and NEMA 4X moderate anti-corrosion protection
Technical Specifications
| Model |
DS-2CD23166G3-I2UY(2.8mm)(eF) |
| Camera type |
Fixed turret network camera |
| Image sensor |
1/1.8-inch progressive-scan CMOS |
| Maximum resolution |
4608 × 3456 |
| Maximum frame rate |
12.5fps at 4608 × 3456 in 50Hz mode; 15fps in 60Hz mode; 20fps at 4608 × 2592; up to 25/30fps at supported 3840 × 2160 and lower resolutions |
| Minimum illumination |
Colour: 0.0008 lux at F1.6 with AGC on; black and white: 0 lux with IR |
| Lens |
2.8mm fixed focal lens, F1.6 |
| Field of view |
Horizontal 94.5°; vertical 69.9°; diagonal 123.2° |
| Depth of field |
2.9m to infinity |
| Physical adjustment |
Pan 0° to 360°, tilt 0° to 75° and rotation 0° to 360° |
| Infrared range |
Up to 40m |
| Wide dynamic range |
130dB |
| Video compression |
H.265+, H.265, H.264+ and H.264; MJPEG on the sub-stream |
| Analytics |
Human and vehicle classification for supported motion and perimeter events; face capture |
| Built-in audio |
Arrayed dual microphone with environmental-noise filtering |
| Speaker and external I/O |
No built-in speaker, external audio input/output or alarm input/output stated for this exact I2UY model |
| Local storage |
microSD, microSDHC or microSDXC card support up to 512GB |
| Network/API |
RJ45 10/100Mbps; ONVIF Profiles S, G and T, ISAPI, SDK and ISUP |
| Power |
12V DC, maximum 8.5W; IEEE 802.3af PoE Class 3, maximum 10.5W |
| Operating conditions |
-30°C to 60°C; relative humidity 95% or less, non-condensing |
| Housing |
Metal cover and metal main body, white finish |
| Protection |
IP67 and NEMA 4X moderate anti-corrosion protection |
| Dimensions |
Ø138.3 × 115.4mm |
| Weight |
Approximately 750g |
High-Resolution Frame Rate
The full 4608 × 3456 stream runs at 12.5fps in 50Hz mode or 15fps in 60Hz mode. The camera can provide 20fps at 4608 × 2592 and up to 25fps or 30fps at supported lower resolutions. This distinction should be considered where smooth motion is more important than maximum pixel count.
Audio and Compatibility
The camera includes dual microphones for audio capture but has no stated speaker, external audio output or alarm interface. It must not be marketed as a two-way-audio or active-deterrence model.
Confirm NVR 16MP decoding, required frame rate, bandwidth, PoE, analytics, storage and mounting compatibility before ordering. NEMA 4X indicates moderate anti-corrosion protection rather than unrestricted severe-environment suitability.
Frequently Asked Questions
What is the maximum resolution?
4608 × 3456, commonly described as 16MP.
What is the frame rate at 16MP?
12.5fps in 50Hz mode or 15fps in 60Hz mode.
What frame rate is available at 4608 × 2592?
Up to 20fps.
What lens is fitted?
A fixed 2.8mm F1.6 lens.
What is the infrared range?
Up to 40 metres.
Does it classify people and vehicles?
Yes, for supported events.
Does it have dual microphones?
Yes.
Does it support two-way audio?
No built-in speaker or audio output is stated.
What storage is supported?
Compatible cards up to 512GB.
What protection applies?
IP67 and NEMA 4X moderate anti-corrosion protection.
