The Hikvision iDS-2CD7A46G2/LM-IZHSY(8-32mm) is a 4 MP DeepinViewX motorized varifocal bullet network camera powered by the Guanlan large model algorithms. It is optimized for high-performance license plate recognition (LPR) and traffic analysis.
Hikvision iDS-2CD7A46G2/LM-IZHSY(8-32mm) 4MP DeepinViewX Bullet Camera
The camera delivers 4 Megapixel (2688 x 1520) resolution at 60 fps, utilizing a 1/1.8" Progressive Scan CMOS sensor. It is equipped with a motorized varifocal 8 to 32 mm lens, F1.2 to F2.5 aperture, extreme 150 dB WDR, and an IR range up to 100 meters.
Housed in an IP67 weatherproof and IK10 vandal-proof enclosure with NEMA 4X anti-corrosion protection, it features a built-in heater for extreme weather operations and a blue glass module to reduce ghosting.
Aluminum Alloy Construction
Constructed from high-quality aluminum alloy, the iDS-2CD7A46G2/LM-IZHSY(8-32mm) provides superior mechanical properties and high structural rigidity. It prevents camera jitter and vibration, ensuring stable, high-definition video feeds in all conditions.
Note: This equipment is designed for professional access control, video intercom, and security operations.
Clean Cable Management
The 4mp deepinviewx bullet camera features a spacious interior channel allowing power and video cables to route cleanly. This internal design protects connections from weathering, corrosion, and vandalism, providing a neat, professional installation.
KEY BENEFITS
- Mounts security and intercom hardware securely on structural surfaces.
- Aluminum Alloy construction provides high durability and structural rigidity.
- Hollow design routes cables internally, protecting wires from UV/rain.
- Durable white finish resists weathering and prevents degradation.
- Suitable for both demanding indoor and outdoor CCTV installations.
- Pre-drilled mounting holes allow for a secure anchor.
- Weight of approximately 3.0 kg provides strong mechanical support.
- Easy installation with standard Hikvision accessory screw layouts.
- Protects mounting surfaces from localized oxidation and rust.
KEY FEATURES
- 4MP DeepinViewX Bullet Camera for security cameras.
- Material: Aluminum Alloy.
- Surface finish: Weatherproof coating.
- Cable routing: Integrated internal channel.
- Application: Indoor and Outdoor environments.
- Weight: Approximately 3.0 kg.
- Dimensions: 347 mm × 144 mm × 144 mm.
- Color: White.
IDEAL FOR
- Commercial building perimeters
- Warehouse brick and concrete walls
- Industrial plant perimeters
- Parking garage pillars and ceilings
- School campus buildings
- Shopping mall exterior walls
- Airport and seaport security structures
- Gated community entrance gates
- Municipal public safety setups
- Public transit platforms
- Hotel exterior walls
- Hospital facility structures
| Specification |
Details |
| Brand |
Hikvision |
| Model |
iDS-2CD7A46G2/LM-IZHSY(8-32mm) |
| Product Type |
DeepinViewX Bullet Camera |
| Resolution |
4 MP (2688 × 1520) at 60 fps |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Lens Type |
Motorized varifocal 8 to 32 mm |
| WDR |
150 dB Super WDR |
| Min. Illumination |
Color: 0.0005 Lux @ (F1.2, AGC ON) |
| IR Range |
Up to 100 meters |
| ShotN Technology |
Clearly captures targets at different speeds |
| Heater Unit |
Built-in (enables startup at -40 °C) |
| Anti-Corrosion |
NEMA 4X & Y-spray coating |
| Ingress Protection |
IP67 / IK10 vandal-proof |
| Power Input |
12 VDC / 24 VAC / PoE |
| Dimensions |
347 mm × 144 mm × 144 mm |
| Weight |
3.0 kg |
Frequently Asked Questions
What is the iDS-2CD7A46G2/LM-IZHSY(8-32mm) used for?
The iDS-2CD7A46G2/LM-IZHSY(8-32mm) is a 4mp deepinviewx bullet camera designed to support security cameras or alarm components while housing and protecting connections.
What is the material of the device?
It is constructed from high-strength aluminum alloy, finished with a weather-resistant finish.
Can this be installed outdoors?
Yes. Where specified by its IP rating, it is suitable for outdoor installations, featuring weatherproof casing to withstand the elements.
Does it support internal cable routing?
Yes. Where applicable, the device or bracket is hollow, allowing you to run power and network cables internally to keep them protected from rain and vandalism.
Are the mounting screws included?
No. You must choose appropriate fixing screws or masonry expansion bolts depending on the structure you are mounting to.
What is the recommended mounting surface?
The mounting surface must be capable of supporting at least three times the total combined weight of the bracket and camera.
