Black Hikvision DS-2CD2747G2H-LIPTRZS2U/SL Product Overview
The black Hikvision DS-2CD2747G2H-LIPTRZS2U/SL combines 4MP video, a motorised 2.8–12mm lens and remote PTRZ adjustment in a dark-finish dome housing. Its 1/1.8-inch progressive-scan CMOS sensor records at up to 2688 × 1520, making it suitable where the installer needs detailed coverage and the ability to refine the view after mounting.
ColorVu imaging, infrared light, white light and Smart Hybrid Light support different low-light and night-monitoring requirements. The camera also provides 130dB WDR, human and vehicle classification for supported perimeter events, built-in dual microphones, a built-in speaker and audio and alarm interfaces. The /SL version adds a white strobe and audible warning for active-deterrence configurations.
Key Benefits
-
Black metal housing: designed for installations where a darker camera finish is preferred.
-
Detailed 4MP video: captures up to 2688 × 1520 for clear monitoring and playback.
-
Remote PTRZ adjustment: pan, tilt, rotation and zoom can be refined through compatible software.
-
Motorised varifocal coverage: the 2.8–12mm lens supports wide-area viewing or a narrower target view.
-
Flexible night modes: infrared, white light and Smart Hybrid Light provide configurable illumination.
-
ColorVu imaging: supports colour-focused low-light performance where scene lighting and settings permit.
-
Human and vehicle classification: deep-learning analytics support compatible perimeter events.
-
Active deterrence and physical protection: the /SL model provides light and audible warnings, with IP66 and IK10 housing ratings.
Key Features
- 4MP network camera with maximum 2688 × 1520 resolution
- Black metal dome housing
- 1/1.8-inch progressive-scan CMOS image sensor
- 2.8–12mm motorised varifocal lens
- Remote pan, tilt, rotation and zoom adjustment
- ColorVu low-light imaging
- Minimum colour illumination of 0.0028 lux at F1.2 with AGC enabled
- Infrared and white-light illumination up to 40 metres
- Smart Hybrid Light operation
- 130dB wide dynamic range
- Human and vehicle classification for supported events
- Built-in dual microphones and built-in speaker
- Audio input/output and alarm input/output
- Memory-card support up to 512GB
- 12V DC or IEEE 802.3at PoE+ power
- IP66 weather resistance and IK10 impact resistance
Technical Specifications
| Model |
DS-2CD2747G2H-LIPTRZS2U/SL(2.8-12mm)/BLACK |
| Camera type |
Motorised PTRZ varifocal dome network camera |
| Image sensor |
1/1.8-inch progressive-scan CMOS |
| Maximum resolution |
2688 × 1520 |
| Minimum illumination |
Colour: 0.0028 lux at F1.2 with AGC on; 0 lux with supplement light |
| Lens |
2.8–12mm motorised varifocal lens |
| Field of view |
Horizontal 114.6°–41.8°; vertical 59.3°–23.6°; diagonal 141.3°–48.1° |
| Maximum aperture |
F1.2 |
| PTRZ adjustment |
Pan 0°–350°, tilt 0°–85° and rotation 0°–350° |
| Supplement light |
Infrared and white light up to 40m with Smart Hybrid Light control |
| Wide dynamic range |
130dB WDR |
| Video compression |
H.265+, H.265, H.264+ and H.264 |
| Analytics |
Human and vehicle classification for supported line-crossing, intrusion, region-entry and region-exit events; face detection support |
| Audio |
Built-in dual-array microphones, built-in speaker and audio input/output |
| Alarm |
1 alarm input and 1 alarm output |
| Active deterrence |
White strobe and audible warning on the /SL model |
| Local storage |
microSD, microSDHC or microSDXC card support up to 512GB |
| Network interface |
1 × RJ45 10/100Mbps Ethernet port |
| Interoperability |
ONVIF Profiles S, G and T; ISAPI; SDK; ISUP |
| Power |
12V DC or IEEE 802.3at PoE+, Class 4 |
| Maximum power consumption |
16W using 12V DC or 18W using PoE+ |
| Operating conditions |
-30°C to 60°C; relative humidity 95% or less, non-condensing |
| Housing |
Metal, black finish |
| Protection |
IP66 weather resistance and IK10 impact resistance |
| Dimensions |
Ø155 × 140.4mm |
| Weight |
Approximately 820g |
Night Imaging, Detection and Deterrence
Infrared, white-light and Smart Hybrid Light modes allow the night-imaging behaviour to be configured for the site. ColorVu supports colour-focused low-light imaging, while white illumination can provide additional visible light when configured. Performance depends on ambient illumination, scene reflectivity, focal length, mounting and settings.
The camera can classify human and vehicle targets for supported line-crossing, intrusion, region-entry and region-exit events. The /SL version's white strobe and audible warning can be linked to compatible events. Built-in dual microphones and the built-in speaker support audio evidence, two-way communication and warning playback.
Installation and Compatibility
The motorised PTRZ mechanism allows the viewing direction and lens setting to be refined remotely through compatible Hikvision software or a supported recorder. This can reduce the need to access and reopen the dome during commissioning or later scene changes.
Use a suitable IEEE 802.3at PoE+ source or a correctly rated 12V DC supply. Confirm recorder resolution support, available PoE budget, analytics compatibility, audio and alarm functions, memory-card compatibility and mounting hardware before ordering. ONVIF Profiles S, G and T assist integration, but third-party recorders might not provide every Hikvision-specific function.
Frequently Asked Questions
Is this the black model?
Yes. This listing is for the black-finish version shown in the product title.
What is the maximum resolution?
The maximum video resolution is 2688 × 1520, commonly described as 4MP.
Can the camera angle be changed remotely?
Yes. Compatible Hikvision software or a supported recorder can adjust pan, tilt, rotation and the motorised 2.8–12mm lens.
What is Smart Hybrid Light?
It allows infrared, white light or an intelligent combined-light mode to be configured according to the monitoring requirement and event settings.
Does it show colour at night?
ColorVu supports colour-focused low-light imaging, and the camera includes white illumination. The result depends on available light, selected mode, scene and settings.
What is the maximum light range?
Hikvision specifies up to 40 metres for infrared and white illumination. Actual performance varies with the scene, focal length and installation.
Does this listing claim AcuSense?
No. Hikvision identifies this exact model as a Smart Hybrid Light with ColorVu PTRZ camera. It supports human and vehicle classification for compatible events without this listing adding the AcuSense product label.
Does it include deterrence features?
Yes. The /SL version includes a white strobe and audible warning that can be linked to supported events.
Can it record to a memory card?
Yes. It supports compatible microSD, microSDHC and microSDXC cards up to 512GB. The card is normally sold separately.
Is it suitable for outdoor use?
The metal housing is rated IP66 and IK10. Installation must still follow Hikvision's sealing, mounting and environmental guidance.
